Exporting a Movie File

T-HFND-010-013

Using the Export Movie dialog, you can export your animation as a video file. By default, Harmony will export your entire scene in its full resolution. If you prefer, you can choose to export only a specific frame range in your scene, or to export in a smaller resolution, which can be useful if you need to save on time or disk space.

If you have specific requirements for the quality and size of your exported video files, you can use the Movie Options dialog to configure the video and audio compression settings. If you're exporting a QuickTime movie, you have access to all of the codecs and compression settings made available by QuickTime's interface.

How to export a movie file

From the top menu, select File > Export > Movie.

The Export to QuickTime Movie dialog box opens.

In the Video Format drop-down menu, select the desired format for your movie file:

Quick Time Movie (*.mov): Available on Windows, macOS and Linux.

Windows Media Video (*.wmv): Available on Windows only.

NOTE: On Windows and macOS, QuickTime must be installed in order to export QuickTime movies. On Linux, Harmony uses a more limited, open source QuickTime-compatible library which does not require additional software.

Click Browse to select the location and file name of your exported movie file.

Click OK.

In the Display Source section, select the Display node to use for rendering your project.

NOTE: If there is no Display node in your scene, the only available option will be Display All. This renders all the nodes in your scene, including ones that are not connected to anything, in the order in which they're listed in the Timeline view. If you wish to have control over what is rendered, it is recommended to have at least one Display node in your scene and to connect it to the composite you wish to render.

From the Export Range section, decide whether you want to export the entire scene (All) or a specific frame range. If you decide on the latter, enter the frame range.
